Build Reports Into Your Flyte Tasks and See Model Results Live

AI engineering tip of the week: Build Reports Into Your Flyte Tasks and See Model Results

‍

Most orchestrators show you logs and a return value. Flyte lets you render full HTML reports - charts, tables, interactive dashboards -right in the UI alongside your task. No separate dashboard tool needed.

Add `report=True` to your task, then use `flyte.report` to push HTML content. It shows up as a tab in the Flyte console while (or after) your task runs.

Render a matplotlib chart

import flyte
import flyte.report

env = flyte.TaskEnvironment(
    name="reporting",
    image=flyte.Image.from_debian_base().with_pip_packages("matplotlib", "pandas"),
)

@env.task(report=True)
async def training_report(epochs: int) -> float:
    import base64, io
    import matplotlib
    matplotlib.use("Agg")
    import matplotlib.pyplot as plt

    # Simulate training metrics
    losses = [1.0 / (i + 1) + 0.05 * i % 3 for i in range(epochs)]

    # Create the chart
    fig, ax = plt.subplots(figsize=(8, 4))
    ax.plot(losses, color="#7652a2", linewidth=2)
    ax.set_title("Training Loss")
    ax.set_xlabel("Epoch")
    ax.set_ylabel("Loss")

    # Convert to embeddable HTML
    buf = io.BytesIO()
    fig.savefig(buf, format="png", bbox_inches="tight", dpi=120)
    buf.seek(0)
    b64 = base64.b64encode(buf.read()).decode()
    plt.close(fig)

    await flyte.report.log.aio(
        do_flush=True,
    )
    return losses[-1]

When this task runs, the chart appears directly in the Flyte UI. No S3 links to click, no separate notebook to open.

Render HTML or Markdown

You can embed complex reports like snippets from video generation or physical AI simulation rollouts from headless environments directly in reports so you don’t have to download artifacts to see how your models are performing.

Use tabs to organize output

Got multiple things to show? Use tabs:

@env.task(report=True)
async def evaluation_report():
    # Tab 1: metrics table
    metrics_tab = flyte.report.get_tab("Metrics")
    metrics_tab.log("<table><tr><th>Model</th><th>Accuracy</th></tr>"
                    "<tr><td>v1v/td><td>0.92</td></tr>"
                    "<tr><td>v2</td><td>0.95</td></tr></table>")

    # Tab 2: chart
    charts_tab = flyte.report.get_tab("Charts")
    charts_tab.log("<p>Chart goes here...</p>")

    await flyte.report.flush.aio()

Each tab shows up as a clickable section in the report view.

Stream updates in real time

Reports aren’t just static, you can stream updates as your task runs for realtime monitoring of training runs

import asyncio

@env.task(report=True)
async def streaming_progress(total_steps: int) -> str:
    for step in range(1, total_steps + 1):
        progress = step / total_steps * 100
        await flyte.report.log.aio(
            f"<p>Step {step}/{total_steps} -{progress:.0f}% complete</p>",
            do_flush=True,
        )
        await asyncio.sleep(1)

    await flyte.report.log.aio(
        '<div style="background:#d4edda;padding:15px;border-radius:5px;">'
        '<h3>Done!</h3></div>',
        do_flush=True,
    )
    return "complete"

The report updates live in the UI as each step finishes. Great for long-running training jobs where you want to watch progress without tailing logs.

Render DataFrames as styled tables

@env.task(report=True)
async def data_summary():
    import pandas as pd

    df = pd.DataFrame({
        "model": ["bert-base", "distilbert", "roberta"],
        "f1": [0.91, 0.88, 0.93],
        "latency_ms": [45, 22, 52],
    })

    tab = flyte.report.get_tab("Results")
    tab.log(df.to_html(index=False, border=0, classes="dataframe"))
    await flyte.report.flush.aio()

Why reports are useful

• Quick feedback loops: See charts and tables without leaving the Flyte UI.
• Experimentation management: Since every run is versioned you can click in to see training and eval reports per task execution
• Shareable: Anyone with access to the Flyte console can view the report -no notebook setup needed.
• Streaming: Watch training curves update in real time.
• Full HTML: Anything you can render in HTML works - D3.js, Chart.js, Three.js, plain tables.

Read more in the flyte docs: https://www.union.ai/docs/v2/flyte/user-guide/task-programming/reports/
